CSP10SHD
CSF10SDI 10.4" HD-SDI Teleprompter Monitor
Description
Technical Specification:
CSF10SDI Monitor
- Screen Size: 10.4" diagonal
- Brightness: 1500 cd/m2
- Contrast Ratio: 3000:1
- Native Resolution: 1024(H) x 768(V)
- Viewing Angle: 180°(H), 180°(V)
- Backlight Technology: High Brightness LED
- Reverse/Rotation: 4-way picture orientation
- Tilt switch activator - automatically switches when unit is vertical or horizontal.
DIMENSIONS
- Front to Back: 8.2” (208.3mm)
- Right to Left: 10” (254mm)
- Depth: 1.5” (38mm)
- Monitor only weight: 2.6lbs/1.2kg
- Complete CSP10SHD prompter weight: 10.3lbs/4.7kg
VIDEO
Autosensing: 3G-SDI/DVI (HDMI)/Composite/VGA/HD Component
POWER CONSUMPTION
- 1.2A @12V DC, 14.4 Watts
ADDITIONAL CONNECTORS
- DC Out: USB 5V
- Tally Sensor: Mini USB - with cue light sensitivity control.
CERTIFICATIONS
- CE, FCC, C-Tick, PSE, RoHs
MOUNTING
- CueLock mounting system built in for fast, secure setup and release.
