EMC17

Technical Specification:

EMC17

• Screen Size: 17” diagonal
• Brightness: 350 cd/m2
• Contrast Ratio: 800:1
• Native Resolution: 1280 x 1024 (SXGA)
• Viewing Angle: 170°(H), 160°(V)
• Backlight Technology: LED
• Controls: Illuminated LED push-buttons with adjustable brightness

DIMENSIONS

• Front to Back: 13.82” (351mm)
• Right to Left: 15.5” (394mm)
• Depth: 1.8” (46mm)
• Monitor only weight: 6.8lbs/3.1kg
• Complete weight with Large Hood, Glass & Mount Purple: 19.8lbs/9kg

VIDEO

• Autosensing: PAL/NTSC/VGA/DVI/HDMI
• Composite: 75 Ohms

POWER CONSUMPTION

• DC power input: 1.9 A / 22.8 Watts
• DC Power Connector: 2.5mm x 5.5mm Center Positive

ADDITIONAL CONNECTORS

• USB – DC Out: USB-A 5V

CERTIFICATIONS

• CE, TUV, FCC, C-Tick, PSE, RoHs

MOUNTING

• CueLock mounting system built in for fast, secure setup and release.
