DE5900

Socket: CPU on board
Type:
Intel 13th Raptor Lake-P core i CPU TDP<=15/28W
i5-1335UE, 1.3~4.5 GHz, 2+8 cores
i5-1340PE, 1.8~4.5GHz, 4+8 cores
i7-1370PE, 1.9~4.8GHz, 6+8 cores

-

-

Channel: Dual Channel
Type: DDR5 SO-DIMM x 2
Data rate: 4800/5200
Max Memory: 96G

Intel Iris Xe Graphics

M.2 slot x1, 2242(key B for 4G/PCIe SSD)
M.2 slot x1, 2280(key M for PCIe /SATA SSD)
M.2 slot x1, 2230(key E for wifi)

Type: Realtek HD Audio ALC265CG
Channel: Stereo

Intel 2.5GLAN x 2 (i226LM+i226V)
100/1000/2500 Mbps

M.2 SSD x2

USB 2.0 Port x2
USB 3.2 Port x2

Others:
Power Button x 1
System error LED x 1
BIOS recovery button x 1
Combo audio jack x 1
RS232 x 1
RS232/422/485 x 1

DC Jack: 12/24V, 5517 x 1
HDMI 2.0 Port: HDMI2.1 x1 + HDMI2.0 x1
USB 3.2 Port x1
RJ45 LAN Jack x2
DisplayPort: USB Type C x 1w/DP
Audio Set:
Line-Out x1
Mic-In x1

Others:
USB Type C x 1w/DP
Extend power SW x 1

AOPEN Fanless design

166(W) x 48(H) x 157(D) mm
6.54(W) x 1.89(H) x 6.18(D) inch

1.25L

1.63kgs / 3.59lbs

1 ~ 255 SEC./ min

"90W (19V, 4.74A) AC Adapter
P/N: 90.CX157.0210 "

AC 100 ~ 240V

2 years

50,000hrs

0 ~50ºC (32 ~ 122ºF)

-30 ~ 60ºC (-22 ~ 140ºF)

90% RH (40ºC non-Condensing)

Windows
Linux
